| Product description |
The 28mm PE Water Bottle Cap Injection Molding Machine is a game-changing addition to the injection molding industry. With its unique ability to transform molten plastic material into a high-quality product using a screw thrust mechanism, it is an invaluable asset to any production line. The machine boasts a highly sophisticated structure, seamless automation, and easy-to-use controls, making it a breeze to operate. Combining hydraulic, electrical, and mechanical controls, it streamlines the production process, delivering more compact and efficient results.
Our company's 28mm PE Water Bottle Cap Injection Molding Machine is a top choice for customers worldwide due to its impressive quality and affordable price point. With high automation capabilities and the ability to produce multiple molds simultaneously, this machine boasts exceptional production efficiency. Additionally, it can handle a wide variety of plastic types, making it ideal for small batch production. Whether you're looking to streamline your production process or simply seeking a reliable injection molding solution, our 28mm PE Water Bottle Cap Injection Molding Machine has you covered.
In today's fast-paced world, the need for convenience has led to a significant rise in the usage of disposable plastic products. This has consequently resulted in a growing demand for injection molding machines, which are capable of producing plastic items on a large scale. As life and work become increasingly rapid, people rely more and more on these machines to cater to their increasing needs. The convenience offered by disposable plastics has played a significant role in their rising popularity. With the increasing demand for these products, injection molding machines have become an essential tool in various industries, allowing for efficient and mass production of plastic goods. As a result, the market for such machines continues to expand, keeping up with the fast-paced demands of modern life and work.
Our machine boasts reliable quality, a short operating cycle and an extended service life. You can trust that it will serve you well for years to come.
| Main Parameters |
| Screw diameter | mm | 35 | 40 | 45 |
| Screw L/D ratio | L/D | 24.5 | 21 | 18.7 |
| Shot weight | gram | 158 | 206 | 260 |
| Injection capacity | cm3 | 173 | 226 | 286 |
| Injection pressure | Mpa | 235 | 180 | 142 |
| Theoretical injection rate | g/s | 110 | 143 | 181 |
| Plastic capacity | g/s | 13.8 | 19.7 | 27.1 |
| Injection stoke | mm | 180 | ||
| Screw torque | N.m | 740 | ||
| Max screw rotate speed | r/min | 250 | ||
| Clamping force | Ton | 130 | ||
| Opening stroke | mm | 400 | ||
| Space between tie bars | mm | 420x420 | ||
| Mould height | mm | 160~440 | ||
| Max daylight | mm | 840 | ||
| Ejector force | ton | 3.14 | ||
| Ejector stroke | mm | 100 | ||
| Ejector quantity | 5 | |||
| Oil pump motor | kw | 15 | ||
| Pump pressure | Mpa | 10 | ||
| Heating power | kw | 9.2 | ||
| Machine size | M | 4.7*125*1.85 | ||
| Machine weight | ton | 4.3 | ||
| Oil tank capacity | L | 360 | ||
| International designation | 1300-410 | |||
| Detail image |
| The main parts |
| Company information |
| Our services & after-sale guarantee |
One-year warranty for core components and lifetime maintenance
One-stop service
Free accessories
Engineer onsite service
Dedicated team
| Certification |
| Service Buyer |
The customer comes first. We think about problems from the perspective of customers and are committed to providing you with the best injection molding solutions. More and more customers around the world are choosing us.
